Figure 16e Chest x-ray from a patient with a bipolar
dual-chamber pacing system. The atrial lead is attached to the right atrial
appendage by activefixation(screw-in lead), and the screw is visible on
the chest x-ray. The ventricular lead is attached to the ventricle by
passive fixation. |
